Brand: Medik

Model: YA-03E

Certificate: CE/ ISO

Overall Size: 2070*550*700-1000mm

Loading Capacity: 250kg

Function: Back section, Foot section, HI-LOW, and Trendelenburg and Reverse

After-sale Service: Online technical support

Warranty:  3-Year on Frame and Welds, and 1-Year on Parts


YA-03E is an electric surgical table with comprehensive functionality and high performance. Hand remote controller with embedded railing controller provides double security during operation. T shape base provides medical staff a closer access to patient with high stability.

Main features

- Divided into 6 parts which can meet the needs of various surgeries

- All metal parts are made of high-grade 304 stainless steel, which is corrosion-resistant and easy to clean

- T-shaped base, which prevents tipping and allows doctors to get as close to the patient as possible, making surgery easier

- Equipped with remote control and column control system

- The transparent platform and sliding functions are suitable for C-arm

- Kidney bridge with adjustable height

- 4 wheels, which are very stable after locking

Accessories

- Anaesthesia screen

- Shoulder support

- Body support

- Arm support

- Leg support

- Foot section

Technical parameter

Table Length2070mm (81.5”)
Table Width550mm (21.5”)
Table Height Range700~1000mm (27.5”~39.3”)
Head section up/down45° / 90°
Back section up/down75° / 20°
Leg section up/down15° / 90°
Leg section outward90°
Trendelenburg25°
Reverse trendelenburg25°
Lateral Tilt (left/right)15° / 15°
kidney bridge 120mm (4.7”)
Sliding300mm (11.8”)
Loading capacity250kg (550lb)



//
